parameTer deTails – “moniTor” menu of parameTers (ConTinued)
P15.8 – True Power P Type:
Description: Read Only
Total True Power. This is a sum of the 3 phases.
Range: Modbus Decimal Value: Default:
0kW – 10,000 kW linear scale (1 = 1W)
True Power (kW) = (Value / 1000)
0kW
Modbus Address: Modbus Format:
34688/34689 ( 8780/8781 hex ) 32-bit unsigned
Touchscreen Menu Path:
Home → Monitor → True Power P
P15.9 – Apparent Power S Type:
Description: Read Only
Total Apparent Power. This is a sum of the 3 phases.
Range: Modbus Decimal Value: Default:
0kVA – 10,000 kVA linear scale (1 = 1VA)
Apparent Power
(kVA) = (Value/1000)
0 kVA
Modbus Address: Modbus Format:
34816/34817 ( 8800/8801 hex ) 32-bit unsigned
Touchscreen Menu Path:
Home → Monitor → Apparent Power S
P15.10 – Reactive Power Q Type:
Description: Read Only
Range: Modbus Decimal Value: Default:
0 kVAR – 10,000 kVAR linear scale (1 = 1VAR)
Reactive Power
(kVAR) = (Value / 1000)
0 kVAR
Modbus Address: Modbus Format:
34944/34945 ( 8880/8881 hex ) 32-bit unsigned
Touchscreen Menu Path:
Home → Monitor → Reactive Power Q
P15.11 – iERS Saving Level Type:
Description: Read Only
Indicates the level of potential saving. 100% indicates that SR55 is saving at its maximum level.
Range: Modbus Decimal Value: Default:
0% – 100% linear scale ( 1 = 0.006104 % )
0% – 100% = (0 – 16384)
x% / 0.006104% = Modbus dec. value
EX: Modbus value of 5250 = 32.05%
0%
Modbus Address: Modbus Format:
35008 ( 88C0 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → Monitor → iERS Saving Level
