Automation Technology C5 Series User Manual

C5 Series User Manual Rev. 1.4

9
C5-2040-GigE
Parameters
Specifications
Responsivity
5.56 V/lux.s
0.27 A/W
With micro lens
@ 550 nm
Shutter Type
Pipelined Global Shutter
QE * FF
60% @ 550 nm
Resolution ( H x V )
2048 x 1088 pixels
Pixel Size
5.5 µm x 5.5 µm
Sensor Size
11.264 mm x 5.984 mm, diagonal: 12.75 mm
Optical Format
2/3”
Power Consumption
6 W
ADC Resolution
10 bit
Dynamic Range
60 dB
Extended Dynamic Range
Up to 90dB with HDR
Max. Internal Full-Frame Rate for Image
Mode
170 fps
Max. External Full-Frame Rate for Image
Mode
(limited due to GigE bandwidth)
50 fps
Effective Profile Rate (Hz) at Max. Row
Width
Number of
Rows
Effective Frame / Profile Rate
(Hz)
8
16
32
64
128
256
512
1088
25000
16000
9540
5240
2700
1400
723
340
