The Sensor Specifications
C5-1280-GigE
Parameters
Specifications
Responsivity
9.6 V/lux.s
Shutter Type
Pipelined Global Shutter
QE * FF
55% @ 525 nm
Resolution ( H x V )
1280 x 1024 pixels
Pixel Size
6.6 µm x 6.6 µm
Sensor Size
8.448 mm x 6.758 mm, diagonal: 10.82 mm
Optical Format
2/3”
Power Consumption
10 W
ADC Resolution
12 bit
Dynamic Range
57 dB
Extended Dynamic Range
Up to 90dB with HDR
Max. Internal Full-Frame Rate for Image
Mode
288 fps
Max. External Full-Frame Rate for Image
Mode
(limited due to GigE bandwidth)
94 fps
Effective Profile Rate (Hz) at Max. Row
Width
Number
of Rows
Effective Frame / Profile Rate (Hz)
1280 Pixel
688 Pixel
1
8
16
32
64
128
256
512
1024
94700
56000
30840
16240
8340
4230
2130
1070
155000
95700
54200
29000
15000
7660
3870
1940
1
C5-1280-GigE can reduce the sensor width to increase the profile rate
