The Digital Outputs
The C5 series features the possibility to output various digital signals. Those signals can be
used to handle further machines or to check the internal signals.
A list of all digital outputs can be found below.
Name
Interface
Access
Visibility
Description
Output1
IEnumeration
RW
Beginner
List the output signals available for first output
(1): Out1_IntegrationActive (Value= 0)
(2): Out1_SequencerActive (Value= 1)
(3): Out1_IntegrationDualSlopeActive (Value= 2)
(4): Out1_IntegrationTripleSlopeActive (Value= 3)
(5): Out1_High (Value= 4)
(6): Out1_Low (Value= 5)
(7): Out1_InternalTrigger (Value= 6)
(8): Out1_SequencerTriggerActive (Value= 7)
(9): Out1_FrameValid (Value= 8)
(10): LightController0 (Value= 9)
Output2
IEnumeration
RW
Beginner
List the output signals available for second output
(1): Out2_IntegrationActive (Value= 0)
(2): Out2_IntegrationDualSlopeActive (Value= 1)
(3): Out2_IntegrationTripleSlopeActive (Value= 2)
(4): Out2_High (Value= 3)
(5): Out2_Low (Value= 4)
(6): Out2_TriggerOverrun (Value= 5)
(7): Out2_ResolverCountDir (Value= 6)
(8): Out2_TriggerBusy (Value= 7)
(9): Out2_AutoStart (Value= 8)
(10): LightController0 (Value= 9)
A detailed description of the digital outputs can be found in a separate
application note.
