C5 Series User Manual Rev. 1.4



The Sensors Spectral Response

300 350 400 450 500 550 600 650 700 750 800 850 900 950 1000

QUANTUM EFFICIENCY [ % ]

WAVELENGTH [nm]

SPECTRAL RESPONSE

C5-1280-GigE C5-2040-GigE / C5-2040-4M-GigE C5-3360-GigE C5-4090-GigE
