C5 Series User Manual Rev. 1.4
The C5 Series General Specifications
Sensor Controls
Synchronization Modes
Free Running, Triggered, Software Triggered
Exposure Modes
Programmable, Pulse Controlled
Shutter Modes
Global Shutter
Digital Input
2 electrical isolated inputs, +5V to +24V DC
VIL, logic “0” Voltage < 1.5V
VIH, logic “1” Voltage > 3.5V
Max. frequency: 450 kHz
Min. pulse width: >2µs
Digital Output
2 electrical isolated outputs, +5 to +24V DC
VOL, logic “0” Voltage < 0.5V
VOH, logic “1” Voltage ≥ 3.8V
IOL, logic “0” drive current max. 100 mA
IOH, logic “1” drive current max. 100 mA
Analog Output
Range: 0V to +5V DC
Encoder/Resolver Input
A+,A-, B+,B-, Z+, Z-
High-Speed Triple RS-422 Receiver
Max. input voltage +5V DC (TTL level)
RS-422-Mode, max. frequency: 15 MHz
Min. pulse width: >32ns
Sensor Features
High Dynamic Range Imaging
Multiple Slope, Multi-Frame Readout
3D-Algorithms
MAX, TRSH, COG, FIR PEAK
3D-Scan Features
Automatic AOI-Tracking, Automatic AOI-Search,
Multiple AOIs, AutoStart
Optical Interface
Lens Mount
M42x1 with flange focal distance 6.52 mm
Adapter for C-Mount lens*
With flange focal distance 17.52 mm
Adapter for Nikon F-Mount lens
with Bayonet mount*
With flange focal distance 46.50 mm
Adapter for Scheimpflug*
For C-Mount lens
* Must be ordered separately. See section Part Number for Scheimpflug Adapter Option
