Automation Technology C5 Series User Manual

C5 Series User Manual Rev. 1.4

11
C5-3360-GigE
Parameters
Specifications
Responsivity
5.56 V/lux.s
0.27 A/W
With micro lens
@ 550 nm
Shutter Type
Pipelined Global Shutter
QE * FF
60% @ 550 nm
Resolution ( H x V )
3360 x 2496 pixels
Pixel Size
5.5 µm x 5.5 µm
Sensor Size
18.48 mm x 13.728 mm, diagonal: 23.02 mm
Optical Format
4/3”
Power Consumption
8 W
ADC Resolution
10 bit
Dynamic Range
61 dB
Extended Dynamic Range
Up to 90dB with HDR
Max. Internal Full-Frame Rate for
Image Mode
52 fps
Max. External Full-Frame Rate for
Image Mode
(limited due to GigE bandwidth)
12 fps
Effective Profile Rate (Hz) at Max.
Row Width
1
Number of Rows
Effective Frame / Profile Rate (Hz)
8
16
32
64
128
256
512
1024
2496
10100
7750
5300
3230
1815
970
500
255
106
1
With a FOT (Frame Overhead Time) = 16
