C5 Series User Manual Rev. 1.4
C5-4090-GigE
Parameters
Specifications
Responsivity
4.64 V/lux.s
0.22 A/W
With micro lens
@ 550 nm
Shutter Type
Pipelined Global Shutter
QE * FF
50% @ 550 nm
Resolution ( H x V )
4096 x 3072 pixels
Pixel Size
5.5 µm x 5.5 µm
Sensor Size
22.528 mm x 16.896 mm, diagonal: 28.16 mm
Optical Format
4/3”
Power Consumption
10 W
ADC Resolution
10 bit
Dynamic Range
60 dB
Extended Dynamic Range
Up to 90dB with HDR
Max. Internal Full-Frame Rate for
Image Mode
32 fps
Max. External Full-Frame Rate for
Image Mode
(limited due to GigE bandwidth)
9 fps
Effective Profile Rate (Hz) at Max.
Row Width
Number of Rows
Effective Frame / Profile Rate (Hz)
8
16
32
64
128
256
512
1024
2048
3072
14500
9700
5800
3200
1700
900
450
225
113
75
