C5 Series User Manual Rev. 1.4

Mechanical Drawings

C5-1280/2040/2040-4M/3360-GigE with M42x1 mount (Standard)

C5-4090-GigE with M42x1 mount (Standard)

Part Number for C5 Series

Part Number #

Product Name

202 203 001

C5-3360-GigE, lens mount M42x1

202 203 002

C5-4090-GigE, lens mount M42x1

202 203 003

C5-2040-GigE, lens mount M42x1

202 203 004

C5-2040-4M-GigE, lens mount M42x1

202 203 005

C5-1280-GigE, lens mount M42x1
