12.11 Basic steps required to program the system
In order to program a basic AutroVoice miniVES conguration and make the system fully operational, follow these steps:
1. Logical output OUT1 – assign the Error event and change it’s generic name to Fault
2. Logical output OUT2 – assign the Alarm mode event and change the generic name to Alarm ACK
3. Add the alarm (evacuation) message and change it’s generic name to Evacuation. Set it’s priority to 10
4. Change the generic name of the Audio input no.3 to Local Audio IN
5. Change the generic name of the built in remans microphone (audio input no.1) to Fire Mic minives XXXX
6. Change the generic name of the built in microphone in general mode (audio input no.2) to Local Mic
7. On the line control cards, change the generic names:
miniVES2001
Zone 1 – lines A+B, Zone 2 – lines C+D, control method: impedance
miniVES4001
card in slot 1: Zone 1 – lines A+B, Zone 2 – lines C+D, control method: impedance
card in slot 2: Zone 3 – lines A+B, Zone 4 – lines C+D, control method: impedance
miniVES4002
card in slot 1: Zone 1 – lines A+B, Zone 2 – lines C+D, control method: impedance
card in slot 2: Zone 3 – lines A+B, Zone 4 – lines C+D, control method: impedance
card in slot 3: Zone 5 – lines A+B, Zone 6 – lines C+D, control method: impedance
card in slot 4: Zone 7 – lines A+B, Zone 8 – lines C+D, control method: impedance
8. Create a Zone group – All Zones and add all of the available zones depending on the AutroVoice miniVES type
9. Create a new matrix and name it Evacuation – add the Evacuation message from the available Audio inputs eld
and the All zones zone group
10. Logical input INPUT1, contact mode – assign the following events:
Active – Alarm mode (start) and General – add the Evacuation matrix (start)
Inactive – Alarm mode (stop)
Change the generic name of the input to Evac activation.
11. In the Events conguration tab:
Assign the built in Emergency buton (1) to Alarm mode event (start) and the select zone event choosing All zones
Key 2 – change the generic name to Evacuation Start and assign the start/stop matricing event (toggle)
Key 3 – change the generic name to LED test and assign the led test event
Key 4 – change the generic name to Stop Evacuation and assign the Alarm mode (stop)
