12.12 Glossary
Function activating modes
Start – selected button or logical input only activates a function programmed in the system.
Stop – selected button or logical input only deactivates a function programmed in the system.
Toggle – selected button or logical input triggers, a change of state to the opposite upon every next activation, acting like an
on / o switch. In case of logical inputs, a necessary condition for reactivation of the function in the toggle mode is returning
to the input’s idle state.
Dynamic assignment
In order to trigger a function whose activation relies on dynamic assignment, follow the predened order. The rst activity is
selection of a zone or multiple zones by means of the programmed Select Zone button, in this way we highlight which zone(s)
thefunction is to aect, then select the button assigned to the function which we want to execute.
Audio inputs – these are all analogue inputs available in the AutroVoice miniVES system to which external sound sources
can be connected to.
Audio outputs – these are all outputs available in the AutroVoice miniVES system, whose parameters are compatible with the
audio inputs of the amplier modules. Control units are equipped with audio outputs, e.g. ABT-CU-11 has 12 audio outputs, as
well as zone microphones which are equipped with 4 outputs.
Audio source – in the AutroVoice miniVES system, an audio source is both a recorded message, regardless of its priority, a linear
audio input on a unit and a zone microphone, as well as the microphone itself.
Individual HV Audio In – this is an input found on each xCtrLine-4 /xCtrLine-2 control card which is used to connect an amplier
modules 100 V output to the card. In the AutroVoice miniVES system it is used exclusively in the 4002 series units to drive two of
the four xCtrLine-2 cards.
System states – there are 4 system states available in the congurator: Alarm mode, Error, Blocking, Backup Power due to which
any function can be activated or an element available in the system can be controled.
Go to Denition is a quick access function which is activated by clicking the left mouse button while moving over onto
the name of any element in the system. This function results in a transition to the card, microphone, device microphone
extension detailed editing window.
Congurator
Software supplied with the AutroVoice miniVES system with the help of which it is possible to manage and program system devices.
FIFO (First IN, First OUT) – in case of conict of two audio sources of the same priority, where Source 1 is already transmitting to
the zone and Source 2 is also to begin transmitting to the same zone, Source No 1 will not be removed in order to make the zone
available for Source No 2 until Source No 1 (matrix) has concluded transmission.
LIFO (Last IN, First OUT) – in case of conict of two audio sources of the same priority, where Source 1 is already transmitting to
the zone and Source 2 is also to begin transmitting to the same zone, Source No 1 will be disconnected from the zone and Source
No 2 will transmit to the zone.
LUA – scripting language used to extend the functionality of the AutroVoice miniVES system. This language is implemented as
the C language library, written according to ANSI C, providing: simplicity, performance and code transferability.
