139
13.1 Fire zones
Fire Zones tab allows routing stored messages / audio input to the selected zones as well as view the status of the speaker lines:
Damage, Blocking, information about broadcasting sources.
Note – the arrows up / down and return are carried out on the buttons placed on the right side of the screen.
In order to route the audio source to the selected zones do the following actions:
1. Select the icon with the name of the zone – select the icon is highlighted in yellow.
2. Select the icon Source:
Select from a list of available audio source or switch icon through Inputs / Messages on the available messages loaded into
the system memory – select from a list and then select Play.
This creates a matrix and its activation – selected audio source to the selected zones. To stop playing the audio source,
selectthesource again and press the Stop icon.
Audio Inputs window
