COMPACT VOICE ALARM SYSTEM
SERVICE MANUAL
Table 1. AutroVoice miniVES series 2001, 4001, 4002 and series 2001N, 4001N, 4002N technical data
Model
AutroVoice miniVES
2001, 4001 and 4002
AutroVoice miniVES
2001N, 4001N, 4002N
Power supply 230V AC, IEC C14 3pin terminal
Power consumption Up to 600 W (depending on conguration)
Number of control slots 4
Message storage
SD HC cards with capacities up to 32GB supported
The included 512MB SLC SDHC card provides more than 20 min of message time
LCD display None
DSP Implemented 3 band parametric EQ
Number of audio inputs 1
Connector type 3 pin phoenix connector
Frequency response 40 Hz… 20 kHz (@1dB) / 400 Hz… 8 kHz (@0,1dB)
Input impedance ≥ 10 kΩ
Maximum input voltage ≥ 3 Vrms
Number of outputs 1
Type of outputs Balanced
Connector type 3 pin phoenix connector
Frequency response 40 Hz… 20 kHz (@1dB) / 400 Hz… 8 kHz (@0,1dB)
Harmonic distortion (THD+IMD) ≤ 0,05%
Headroom 10 dB
SNR ≥ 90 dB
Channel separation ≥ 80 dB
Output impedance 600 Ω
Nominal output level 1 Vrms
Data communication
Standard communication:
 1000BASE-TX/RJ45
CAT5E cables – 2 ports
available on the connector panel
 100BASE-TX/RJ45 CAT5
cables – 1 port available
on the connector panel, for
connections with an external network
Communication over large distances:
 1000BASE X optical ber
 2 ports providing
a redundant connection
Standard communication:
 1000BASE-TX/RJ45
CAT5E cables – 2ports
available on the connector panel
 100BASE-TX/RJ45 CAT5
cables – 1 port available
on the connector panel, for
connections with an external network
