Table 6. Technical data of ABT-xCtrLine-2
Model ABT-xCtrLine-2
Power supply Internal form the Control Unit backplane
Maximum current consumption 121mA for 48V
Type of connector 6 pin screw terminal type PHOENIX, 5.08 mm
Impedance measurement frequency 1 kHz to 48 kHz
Frequency of the signal for EOLmodules 18 kHz to 24 kHz
Maximum measured current 20 A
Maximum measured voltage 200 V
Accuracy of measurement Up to 5%
Operating temperature 0°C to 60°C
Operating Humidity 15% to 80%
Storage Temperature -20°C to 70°C (non-condensing)
Storage Humidity 5% to 95% (non-condensing)
Dimensions 70 x 215 x 30 (mm)
Accessories
Screw terminals 6 pins,
the distance between the partitions 5.08 mm
