Autronica AutroVoice miniVES Series User Manual

41
Table 8. Technical specication of the AutroVoice miniVES Charger card
Model AutroVoice miniVES Charger
Electrical
DC main power supply 54VDC from Power Supply Unit
DC input Edge connector to backplane
DC input protection 15A 63VDC SMD slow-blow fuse (non replaceable)
DC outputs
Internal (edge connector):
 2x 48V for power ampliers, each output max. 10A 42…57VDC
 48V for PoE, max. 1A
 5V max. 3A
 12V max 1,7A
 -12V max 0,3A
Ext (Phoenix-type connector, 3.5 mm raster):
 1x 24V max. 0,15A
 1x48V max. 0,35A
DC output protection
Int:
 Ampliers supply: replaceable fuses 58VDC Low Prole
Mini 891 series blade fuse
 5A for 2xxx series, 10A for 4xxx series
Ext:
 48V output: 0,5A non replaceable PTC fuse
 24V output: 0,2A non replaceable PTC fuse
Summary maximum
all DC output loads
Total output DC load shouldn’t exceed 500W
Backup Power Supply
Battery (type) 4 pcs., VRLA 12 V 15-200 Ah
Charging method constant voltage or multi-stage
Charging current 2,3 A max.
Charging voltage 54,6 V ± 0,6 V (at 25°C)
Temperature correction coecient -80 mV/ °C
Battery connection
Dedicated wiring
Phoenix Contact 1720466 with AWG8 connection cord 4x12 V
Battery circuit protection
Fuses 58VDC Low Prole Mini 891 series blade fuse
Positive cord: 7,5A for 2xxx series, 15A for 4xxx series
Negative cord: 20A
Maximum total serial resistance
ofwiring, fuses and batteries
60 - 160 mΩ (adjustable in conguration SW)
Temperature
Temperature sensor Dedicated temperature sensor
Operating temperature -5°C to +40°C
