45
Listening speaker
Output 0,5 W
SPL 78 dBA (@1m, 1W)
Frequency response (3dB) 450 Hz … 8 kHz
Audio input
Frequency response 400 Hz – 6 kHz (@3dB)
Impedance 500
Signal -40 to 30 dBu
Sensitivity -66 dB
Cable type, length spiral - 1,5 m
Microphone connector 5 pin DIN
Keyboard and controls
Number of buttons 3
Number of control panel buttons 2 LED / button
Dimensions of the buttons description 15x25 mm
Three normative LED controls color LEDs: power – green / failure – yellow / alarm – red
Logic Input / Output
Number of I / O logic
2 independent channels; galvanically isolated;
each channel has 1 fully programmable input and output (NO / NC)
Parametric input source for monitor mode
passive; standard resistors 10 k || 10 kΩ or 4,7 kΩ - - 4,7 kΩ
detection thresholds 0/1 / open / set in the application conguration
Type of socket I / O logic 6-pin screw terminal type PHOENIX, 3.5 mm
CPU-OFF switch slide switch, two position, signaling LED color: yellow
Other parameters
Operating temperature 0°C to 60°C
Operating humidity 15% to 80%
Storage temperature -20°C to 70°C
Storage humidity 5% to 95%
Dimensions 150 (W) x 55 (H) x 210 (D) mm
Accessories
connector with screw terminals 6 pins, the distance
between the partitions 5.08 mm
