3.7 Alarm Presentation with Zonal Indication (optional)
Note that the optional alarm presentation with zonal indication is
used throughout the handbook.
FIRE ALARMS, for example, is shown highlighted in the upper left
corner of the display.
The example below shows a situation where three zones are in alarm
state. The total number of zones in alarm is shown in the upper right
corner.
1 OFFICES
2 CANTEEN
3 WORKSHOP
FIRE ALARMS
19:23
Total: 3
Zones in alarm
Total number
of zones in alarm
