Procedure
1. On the Device Physical View, select a port or ports.
2. From the navigation tree, double click Edit.
3. From the Edit tree, double click Chassis.
4. From the Chassis tree, click Ports.
5. Click the Interface tab.
6. To change the configuration of the selected ports, in the Multiple Port Configuration
pane, double-click the cell beneath the column heading that represents the
parameter you want to change and do one of the following:
• Select a value from a drop-down list.
• Type a value in the cell.
7. In the Make Selection pane, click Apply Selection.
The changes appear in the table.
8. On the Interface tab toolbar, click Apply to apply the changes to the switch
configuration.
Example 2 — Configuring multiple ports using EDM
The following procedure provides sample steps for configuring multiple ports using the Multiple
Port Configuration function and the Security > MAC Security > AutoLearn workflow. When
you use this, and similar workflows, you can select ports directly from the Multiple Port
Configuration pane on the configuration tab. If you use the Edit > Chassis > Ports workflows
you must first select ports on the Device Physical View.
Procedure steps
1. From the navigation tree, double click Security.
2. From the Security tree, click MAC Security.
3. Click the AutoLearn tab.
4. In the work area, in the Make Selection section of the Multiple Port Configuration
pane, click the Switch/Stack/Ports ellipsis (...) to open the Port Editor dialog.
5. In the Port Editor window, click the ports you want to configure.
Note:
If you want to configure all ports, click All.
6. Click OK to return to the Make Selection pane.
The ports you selected appear in the Switch/Stack/Ports box.
Enterprise Device Manager procedures
Fundamentals December 2011 49
