E1070 Service Manual 141
6.3 Communications Timeout:
Transmit 20000 lb of Gross weight with Gross, Motion, and all Under bar(UB1-6)
segments turned on. A typical serial string is as follows:
Mode 3&4 Serial String:
G<SP>20000<SP>lb<CR><AN1><AN2><AN
3><AN4><AN5><AN6><AN7><AN
8><
CR>
<LF><AN1> = 0x00 <AN2> = 0x38 <AN3> = 0x00 <AN4> = 0x00
<AN5> = 0x01 <AN6> = 0x00 <AN7> = 0x3E <AN8> = 0x00
6.3 Communications Timeout:
If communications is lost between the host and the remote, the remote will display “-“,
middle dashes until a signal is acquired again. The timeout for this error to occur should
be 5-10 seconds in duration.
Table 3: Remote keypad press protocol
Command Description of command
Z<LF> Emulates a Zero key press
S<LF> Emulates a Select key press
T<LF> Emulates a Tare key press
P<LF> Emulates a Print key press
U<LF> Emulates a Units key press
F<LF> Emulates an F1 key press
