E1070 Service Manual 71
3.4 Service Menu
CAL (Calibration audit counter)
1. With CFg displayed, press the UNITS key…
CAL is displayed. This stands for the Calibration audit counter. Use this
item to see how many times this indicator has been calibrated.
2. Press the PRINT key…
A number is displayed. This is the number of times this indicator has
been calibrated.
3. Press the SELECT key twice…
Audit is displayed.
This completes the AUDIT submenu. Press the UNITS key to go to the INPUT
submenu or press ESC to return to normal weighing mode.
3.4.9 INPUT submenu
The next section of the Service menu is the INPUT submenu. See Figure 3.10. This
menu lets you configure the inputs of the indicator.
Figure 3.10 INPUT submenu
Follow these steps to access and configure the inputs:
1. Use the instructions in Accessing the Menus on page 19 to access the Service
menu…
CAL is displayed.
2. Press the UNITS key repeatedly until…
InPut is displayed.
3. Press the PRINT key…
1 is displayed. This stands for input #1. You can scroll to each input by
using the TARE or UNITS key. When you access each input, by
pressing the PRINT key, you get to choose from this list of input types:
nonE Input does nothing
ZEro Input zeroes the scale
tArE Input tares the scale
