NOTE TORQUE SPEC:
All M5 fasteners- 25.0 in. lbs., [3.0 N/m]
All M3.5 fasteners- 12.0 in. lbs., [1.35 N/m]
ITEM
NO.
DESCRIPTION W-T P/N QTY
1 Enclosure (stainless steel) 55909-0071 1
2 AC Power Cord (USA)
AC Power Cord (UK)
49180-0116mts
49180-0124mts
1
1
3 Cover (stainless steel) 55907-0016 1
4 Gasket 55908-0015 1
5 Relay Control PC Board Assy 56957-0013mts 1
6 Neoprene Plug (1/4” dia.) 27429-0014
7 Neoprene Plug (8mm dia.) 27429-1087
8 Nut, Hex, M5 x 0.8 46574-0090 11
9 Screw/Washer Assy, M3.5 x 6mm 55511-0014 5
10 Power Supply,
100-240VAC, 12VDC 2.2A
AWT25-000674 1
11 Neoprene Washer 26357-0020 6
12 Neoprene Washer 26357-0053 2
13 Strain Relief 55177-0027 6
14 Strain Relief 55177-0043 2
15 Lock Nut 55177-1025 6
16 Lock Nut 55177-1041 2
To Next Page
