3.4 Service Menu
Notes:
These tokens can be optionally followed by an ASCII 2 to 9 to specify the number of
weight digits (including decimal point). If no specifier is given it defaults to 6 digits (+
decimal point) (equivalent to ASCII 6).
Further, parameter values may be ASCII digits (i.e. range ‘0’ thru ‘9’) or DECIMAL
values (i.e. range 0 thru 255). In all cases, parameters consume one byte. In the term/
token table parameters are indicated as follows:
Optional, (ASCII) - (,n)
Optional, (Decimal) - (,x)
Mandatory, (ASCII) - ,n
Mandatory, (Decimal) - ,x
151 97 GTO Gross Accumulator Weight
152 98 GTU Clears G, T or N Accum in print Misc.
153 99 STO Net Accumulator Weight
155 9B PLU PLU NumberData PLU
156 9C DES PLU ID PLU
162 A2 DIS Remote Display Status Miscellaneous
170 AA VER Software Version Number Miscellaneous
173 AD WST Weight Steady Weight
178 B2 PUP Tare associated with the PLU PLU
184 B8 PUT PLU Totals Information PLU
188 BC PCT PLU Count Total PLU
189 BD LST Net Accumulator PLU
190 BE LGT Gross Accumulator PLU
200 C8 DSP(,n) Print the displayed weight Weight OPTIONAL, (ASCII)
Range: (‘2’-‘9’), Indicator Default: ‘6’
215 D7 NULL Null Token Strings
216 D8 ACT Print the active value (‘G’ for
gross, ‘N’ for net, ‘T’ for tare)
Weight
230 E6 DRT Remote display token-Axle
mode
Vehicle
231 E7 HST Active Value-Axle mode Vehicle
233 E9 AXT Axle total Vehicle
242 F2 PWT Peak Hold Weight value Weight
246 F6 MWR Axle index Vehicle
253 FD HEX,xx Following number will be
transmitted by value. Also,
use this selection to
transmit a NUL as well.
Hex-Codes MANDATORY, (ASCII-HEX)
Range: (00 – FF), Editor Default: 00
254 FE TEX Reserved for future use
as a ‘token extender’
-----
255 FF EOS End of String String
Table 2: Printing Commands Chart
