50 Model E1070 Indicator User Instructions
Indicator Operations
5.3 Print Operations
This indicator has multiple print functionality.
Method 1 - Each application can use multiple print formats. (This is
configured from a password protected menu. Contact your local Avery
Weigh-Tronix supplier or distributor for assistance. Press the PRINT key to
print all the configured print formats.
Method 2 – With multiple print formats configured, selecting the number of
that print format will print only the selected format.
Example: Checkweigher application using print formats 1, 2, 3 and 4. Each
print format references a different customer. Press 1 then the PRINT key to
print only print format 1. Press 2 and the PRINT key to print only print format
2.
5.4 General Gross Weighing
To perform general gross weighing, power up the unit and follow these
steps:
To change unit of measure, press
the UNITS key.
1. Empty the scale and press ZERO key to zero the display…
0 is displayed.
2. Place item to be weighed on the scale…
Weight is displayed.
5.5 General Tare/Net Weighing
To perform a general net weighment, power up the unit and follow these
steps:
1. Empty the scale and press ZERO key to zero the display…
0 is displayed.
2. Place item to be tared on the scale…
Weight is displayed.
3. Press the TARE key…
0 is displayed and the NET annunciator lights.
4. Place material to be weighed on the scale…
Net weight of material is displayed.
To clear a tare weight, remove all
weight from the scale and press
the TARE key.
5. Repeatedly press the SELECT key to scroll through gross, tare, and
net modes. Remove the weight from the scale and press TARE to
return to gross mode.
