80
Model E1070 Indicator Service Manual
Token Inbound Outbound Inbound Outbound Token Token
to net1 from net 1 to net 2 from net 2 (dec.) (hex)
Gross X X 0 00
Net X X 1 01
Tare X X X X 2 02
Peak X X 3 03
Count X X 4 04
PLU Piece weight X X X X 5 05
PLU number X X X X 6 06
PLU Gross Accumulator X X 7 07
PLU Net Accumulator X X 8 08
PLU Total counter X X 9 09
PLU Count Accumulator X X 10 0A
PLU Tare value X X X X 11 0B
PLU ID X X X X 12 0C
PLU Lower Target weight X X X X 13 0D
PLU Upper Target weight X X X X 14 0E
Recipe Ingredient number X X 15 0F
Recipe Ingredient target weight X X 16 10
Recipe Ingredient actual weight
when target is met X X 17 11
Motion/Weigher Steady X X 18 12
Center of Zero/zero balance X X 19 13
Overload X X 20 14
Underload X X 21 15
Input1-3 X X X X 22 16
Output 1-3 X X X X 23 17
Serial number X X 24 18
Watchdog counter X X 25 19
Remote zero X X 26 1A
Remote tare X X 27 1B
Remote print X X 28 1C
Remote accumulate X X 29 1D
Bridge1 X** X* X* X** 30 1E
Bridge2 X** X* X* X** 31 1F
Bridge3 X** X* X* X** 32 20
Bridge4 X** X* X* X** 33 21
Bridge5 X** X* X* X** 34 22
Bridge6 X** X* X* X** 35 23
Bridge7 X** X* X* X** 36 24
Bridge8 X** X* X* X** 37 25
Bridge9 X** X* X* X** 38 26
Bridge10 X** X* X* X** 39 27
Bridge11 X** X* X* X** 40 28
Bridge12 X** X* X* X** 41 29
Bridge13 X** X* X* X** 42 2A
Bridge14 X** X* X* X** 43 2B
Bridge15 X** X* X* X** 44 2C
Bridge16 X** X* X* X** 45 2D
Indicator Healthy X X 46 2E
Service Menu—OPTION submenu (continued)
Table 4
Tokens
* Bridge tokens that are inbound to net2 can be outputs for net1
** Bridge tokens that are inbound to net1 can be outputs for net2
