Model E1070 Indicator Service Manual
27. Press the PRINT key…
SMA or Enq is displayed.
28. Toggle between the two choices using the TARE and UNITS keys.
When the desired choice is shown, press the PRINT key to select it.
SMA – the SMA protocol over the Ethernet connection. This is the
exact same protocol used on the serial ports. See the Service-
Serial section of this manual for details.
Enq – If Enq is chosen you will be prompted to key in a polling charac-
ter. This can be any value from 0 to 255. Example: if the desired
polling character is a carriage return, enter 13 for the polling
character. After the polling character is keyed in, press the
ENTER key and the display will return to protcL. When the
polling character is received on the Ethernet connection, the
indicator will act as if the PRINT key has been pressed (all of
the formats-to-print will be sent out of the configured port). If you
want the print format(s) to be sent back on the Ethernet connec-
tion, the print formats must be configured for tcpip1 (net1) or
tcpip2 (net2). See the Service-App and Service-Serial sections
of this manual for details on setting up the print formats.
29. This completes the Ethernet TCP/IP Server configuration. Press the
ESC key to exit the service menu.
Service Menu—OPTION submenu (continued)
