EN21EN 20
C - INSTALLATION
3.4 - Installing the motors - for opening towards the outside of the property
• Place the mounting brackets against the posts, 14mm above the rigid part of the gate where the ends of
the pivoting arms will be fastened.
1m maximum
recommended
14mm
Inner side of the property
• Use plugs and screws that are suitable for the post material (example: for concrete, use ø12mm plugs
and ø8mm lag screws with a length of 80mm). After tightening, the mounting bracket must be completely
horizontal and 14mm above the middle of the rigid part of the gate. Make sure not to weaken the posts.
view from above
