1.4. Safety rules
The actual opening of a gate may create dangerous situations for people, goods and vehicles in the vicinity
that by nature, cannot always be avoided by design.
The possible hazards depend on the state of the gate, the manner in which it is used and the installation site.
After having checked that the gate to be motorised complies with the requirements given in this chapter and
before beginning the installation, a hazard analysis of the installation must be conducted in order to eliminate
all dangerous situations or to indicate them if they cannot be eliminated.
2. ELIMINATION OF HAZARDS
The hazards posed by a two-panel motorised gate, as well as the adapted solutions to eliminate those
hazards, are as follows:
2.1. Subpanels
Following installation, there may be a shear zone between the panel and the corner of the post.
In this case, it is recommended to remove this zone leaving a minimum working distance of 25mm either by
positioning the side stops accordingly or by notching the corner of the posts without weakening them, or
both if necessary.
If this is not possible, the hazard must be clearly indicated.
For opening towards the outsideFor opening towards the inside
side
stop
side
stop
side
stop
side
stop
side
stop
shear zone
shear zone
25mm
min
25mm
min
25mm
min
post post post
view from above view from above view from above view from above
Solution SolutionHazard Hazard
OR
post post
2.2. Bottom edges
Following installation, there may be a dangerous zone for toes between the bottom edge of the gate and the
ground, as indicated in the following figure.
In this case, this area must be removed leaving a working distance of minimum 50mm or maximum 5mm.
C - INSTALLATION
