C - INSTALLATION
30cm mini
60cm maxi
RX1
RX1
pair 1
pair 1
pair 2
pair 2
10 cm min 15 cm max
10 cm min 15 cm max
TX1
TX1
90°
90°
90°
90°
RX2
RX2
TX2
TX2
Opening inwards
view from above
Opening outwards
view from above
