EN15EN 14
C - INSTALLATION
3.3 - Installing the motors - for opening towards the inside of the property
• Place the mounting brackets against the posts, 14mm above the rigid part of the gate where the ends of
the pivoting arms will be fastened.
1m maximum
recommended
14mm
• Use plugs and screws that are suitable for the post material (example: for concrete, use ø12mm plugs
and ø8mm lag screws with a length of 80mm). After tightening, the mounting bracket must be completely
horizontal and 14mm above the middle of the rigid part of the gate. Make sure not to weaken the posts.
x
axe du gond
