EN69EN 68
Consumption at rated strength 3A
Assigned operating duration 10 cycles per hour
Maximum number of cycles 100 cycles per day
Operating temperature -20°C/ +60°C
Protection rating IP44
FLASHING LIGHT
Type
LED lighting 8W max, flashing managed
by the electronic card
Power supply 24V impulse relay
Operating temperature -20°C/ +60°C
Protection rating IP44
REMOTE CONTROL
Type
OOK AM modulation. 16-bit Rolling code encoder (i.e.
65,536 possible combinations)
Frequency 433.92 MHz
Open air range 80 m
Power supply CR2032
Touch-sensitive 4 keys
Radiated power < 10 mW
Battery life 1 year at a rate of 10 x 2s uses per day
Operating temperature -20°C/ +60°C
Protection rating
IP40 (For indoor use only: home, car or sheltered
location)
OPTION
Type
Modular infrared beam presence detector.
D type safety system according to EN 12453
Contents 1 TX transmitter and 1 RX receiver
Power supply 12VDC, 12VAC, 24VDC, 24VAC
Maximum assigned power 0.7W for the pair
G - TECHNICAL AND LEGAL INFORMATION
