IntheOptionscolumn,clickonthePortsiconopenPortOptions.
l
ClicktheInputTypedropdowntochangeaContactSensor,RequesttoExitinputorAUXI/Otoa
differentinputtype,WiegandDevice,ortoaGenericinput.Thisisusefulforcreatingrules.SeeRuleson
page124.
l
YoucanonlychangetheInputTypeonaportthathasnotyetbeenassignedtoanentry.
End-of-linesupervision
TheSDCandCoreSeriesSmartHubssupportend-of-line(EOL)supervision:
l
ClicktheCableicontoopenCableOptions.
l
ClicktheEndofLineSupervisionlisttoselectLineShortedDetect,LineCutDetect,orBoth.
l
Thesettingselectedmustmatchyourphysicalwiringconfiguration,seetheOpenpathAccessControl
SystemInstallationGuideformoreinformation.
Devices 77
