14
User Manual
Weight: 800 g
LCD display
• color TFT 7” (16:9)
• resolution 800 x 480 pixels
Antenna dimensions
• 3” diameter, 0.625” height (76.2 mm diameter, 15.9 mm height) (Antenna
includes a 5 meter cable)
Power consumption
• color 10 Watt, 10–35 Volt DC
Operating Temperature Range
• 32°F to 131°F (0°C to 55°C)
Storage Temperature
• -13°F to 158°F (-25°C to 70°C)
Memory
• Non volatile with battery back-up
Keyboard
• Backlighted, silicon rubber
1.2 BASIC
Fig. 1.2 - How to insert the Compact Flash
The EKP-IV is controlled by using 10 keys. As you press a key, a single audio
beep confirms the key action; every time the key pressed is not valid, three
rapid beeps sound indicating that no response is available.
POWER Key - For quick access to the GPS status tap the 'POWER' key. The
Brightness and contrast will appear; the GPS status and current time are dis-
played at the bottom of this box.
