90
User Manual
the EKP-IV close at hand and in an easily visible location without interfering with
other equipment.
Use the elastic strap provided to secure the EKP-IV to your leg. Position the
elastic strap around your leg with the long looped strip on top. Fasten with the
hook and loop closure at each end of the strap. Hold the EKP-IV over the strap
on your leg and lower into place.
Press down a little to be sure the strips are secure. If you prefer there are after
market mounts available for attachment to the yoke assembly or the seat rail
tracks. Please contact your dealer for more details on these items.
NOTE
Yoke mounts may not be appropriate for your aircraft. Use care to ensure that the EKP-IV does
not obscure the primary instruments.
15.3 DIMENSIONS
Fig. 15.3 - Dimensions
