27
5.4.3 DETECTION
ADVANCED CONFIG
C O N N E CTIO N CH1 CH2 CH3 CH4
CAMERA
ALARM OFF
DETECTION
SENSITIVITY 0
ALERT
MOTION ON
NETWORK
AREA EDIT
DISPLAY
INTERNAL ALARM ON
RECORD
NOTIFY
EXIT
1) ALARM
Select N.C./ N.O depending on your installation need. The default alarm value is OFF.
2) SENSITIVITY
Select the detection sensitivity of the selected channel, the lower the value, the higher the sensitivity.
3) MOTION
Select if you want to activate the motion detection function for the selected channel (ON/OFF).
4) AREA
Click “EDIT” to set the motion detection area.
There are 16 × 12 grids per camera for all channels. Pink blocks represent the area that is not being detected
while the transparent blocks are the area under detection.
Note: To exit area setting and return to the detection page, right click your mouse.
5) INTERNAL ALARM (For selected camera models only)
This function appears only when the camera connected supports human detection.
Select “ON” to enable human detection, or “OFF” to disable it.
5.4.4 ALERT
ADVANCED CONFIG
CONNECTION
EXT. ALERT ON
CAMERA
INT. BUZZER OFF
DETECTION
KEY BUZZER ON
ALERT
VLOSS BUZZER ON
NETWORK
MOTION BUZZER ON
DISPLAY
ALARM BUZZER ON
RECORD
HDD BUZZER ON
NOTIFY
ALARM DURATION (SEC) 5
EXIT
1) EXT. ALERT
Select to enable or disable the sound when any external alarm is triggered (ON / OFF).
2) INT. BUZZER
Select to enable or disable the sound (ON / OFF) for all internal buzzers: KEY BUZZER, VLOSS BUZZER,
MOTION BUZZER, ALARM BUZZER, and HDD BUZZER.
Note: When this item is set to “OFF”, item 3) to item 7) will be disabled even though they are set to ON.
3) KEY BUZZER
Select to enable or disable the sound when pressing the buttons on the front panel (ON / OFF).
