APPENDIX 6 PRODUCT SPECIFICATIONS
41
APPENDIX 6 PRODUCT SPECIFICATIONS
4CH
Model 1 Model 2
Hardware
Video Input 4 LAN ports
Video Output HDMI
Video Output Resolution 1920 x 1080
HDD Storage** One 3TB HDDs
eSATA
YES
(support up to 4-bay disk array with RAID 0 and 1)
USB Ports
Two on the front panel:
one for video backup to USB flash drive, and another for NVR control via a USB
mouse
IR Remote Control YES
LAN port
10/100Mbps with PON 10/100Mbps with POE
Ethernet
Internet (WAN) port
1000Mbps
Software
Video Compression Format H.264
Local / Remote Display Mode 4CH
Loca / Remote Playback Mode 4CH
Single Channel Playback YES
Recording Mode Manual / Event / Alarm / Schedule
Recording Throughput Up to 120IPS @ 1280 x 1024, 32 Mbps
Pre-alarm Recording YES
Quick Search Time / Event
Event Notification Message Mail / Video Mail
Push Video / Push Status / Message
Mail / Video Mail
Security 4 user access levels with password
Remote Access
(1) Internet Explorer on Windows operating system
(2) EagleEyes on iOS & Android mobile devices
(3) Our self-developed program, Video Viewer
General
Power Source (±10%) DC 48V / 1.25A
Power Consumption (±10%)
7.68W
(without a hard disk and POE IP camera connected)
Operating Temperature
10℃ ~ 40℃ (50℉~104℉)
Dimensions (mm)** 345 (L) x 225 (W) x 68.3 (H)
Minimum PC Browsing Requirements
‧Intel core i3 or higher, or equivalent AMD
‧2GB RAM
AGP graphics card, Direct Draw, 32MB RAM‧
Windows ‧ 7, Windows Vista & Windows XP, DirectX 9.0 or later
Internet Explorer ‧ 7.x or later
Peripherals
Power-over-Coaxial Converter
* Specifications are subject to change without notice.
** Hard disks are optional
** Dimensional tolerance: ±5mm
