Chapter 7. LIST OF SIMPLE CONFIGURATION DISPLAY ITEMS
Display Item Contents
Initial value
Notes
Operation type of Same as operation type of internal 0
internal contact 2 contact 1
Operation type of Same as operation type of internal 0
internal contact 3 contact 1
Key lock 0: All settings are enabled. 0 When two sets of passwords (1A and
1: Mode, event, operation display, 1B, and 2A and 2B) are met, the
SP, UF, lock, manual MV, and settings can be made.
mode key can be set. Mode key setting, MV setting in the
2: Operation display, SP, UF, lock, MANUAL mode, key lock, password
manual MV, and mode key can display, and password 1A to 2B
be set. settings can be made when the key
3: UF, lock, manual MV, and mode lock (LoC) is 0 to 3.
key can be set.
Password display 0 to 15 0 "0" is set whenever the power is
5:
Password 1A, 2A, 1B and 2B display
turned ON.
Password 1A 0000 to FFFF (hexadecimal value) 0000 Displayed when the password display
(PASS) is "5" and two sets of
Password 2A 0000 to FFFF (hexadecimal value) 0000
passwords (1A and 1B, 2A and
2B) are met.
Password 1B 0000 to FFFF (hexadecimal value) 0000 Displayed when the password display
(PASS) is "5".
Password 2B 0000 to FFFF (hexadecimal value) 0000
