Chapter 7. LIST OF SIMPLE CONFIGURATION DISPLAY ITEMS
Display Item Contents Initial value Notes
Operation type of Same as operation type of internal 0
internal event 2 event 1.
Internal event 2 Same as internal event 1. 0000
1st digit: Direct/Reverse
2nd digit: Standby
3rd digit: Operation
at READY
4th digit: Undefined
Operation type of Same as operation type of internal 0
internal event 3 event 1.
Internal event 3 Same as internal event 1. 0000
1st digit: Direct/Reverse
2nd digit: Standby
3rd digit: Operation
at READY
4th digit: Undefined
Operation type of Same as operation type of internal 0
internal event 4 event 1.
Internal event 4 Same as internal event 1. 0000
1st digit: Direct/Reverse
2nd digit: Standby
3rd digit: Operation
at READY
4th digit: Undefined
Operation type of Same as operation type of internal 0
internal event 5 event 1.
Internal event 5 Same as internal event 1. 0000
1st digit: Direct/Reverse
2nd digit: Standby
3rd digit: Operation
at READY
4th digit: Undefined
Operation type of 0: No function 0 For details, refer to the section,
internal contact 1 1: LSP group selection (0/+1) Internal contact operation type
2: LSP group selection (0/+2) setup (on page 5-37).
3: LSP group selection (0/+4)
4: Invalid
5: Invalid
6: Invalid
7: RUN/READY selection
8: AUTO/MANUAL selection
9: Invalid
10: AT Stop/Start
11: ST disabled/enabled
12:
Control action direct/reverse selection
(As setting/opposite operation of
setting)
13: SP RAMP enabled/disabled
14: PV Hold (No-hold/Hold)
15: PV maximum value hold
(No-hold/Hold)
16: PV minimum value hold
(No-hold/Hold)
17: Timer Stop/Start
18: Release all DO latches
(Continue/Release)
19: Invalid
20: Invalid
