• Transportation conditions
Ambient temperature: -20 to +70˚C
Ambient humidity: 10 to 95%RH (No condensation allowed.)
● Other specifications
Degrees of protection: Front panel of the unit conforms to IP66/NEMA 4X.
(Individual panel mounting with attached gaskets)
Power consumption: AC power model, Max. 12VA (8VA at 100Vac and 12VA at
264Vac)
(When using the functions similar to those of Azbil Corporation’s
SDC10, the power consumption is 6VA at 100Vac and 9VA at
264Vac.)
DC power model, Max. 7VA (24Vac), Max. 5W (24 to 48Vdc)
Altitude: 2000m or less
Insulation resistance: Between power supply terminal and secondary terminal, 500Vdc,
20MΩ or more
Dielectric strength: AC power model, Between power supply terminal and secondary
terminal, 1500Vac for 1 min.
DC power model, Between power supply terminal and secondary
terminal, 500Vac for 1min.
Inrush current at power ON: AC power model, Max. 20A
DC power model, Max. 20A
Mass: Panel mounting type Approx. 150g (including mounting bracket)
Socket mounting type Approx. 200g (including socket)
Terminal screw tightening torque: Panel mounting type 0.4N·m or less
Socket mounting type 0.78 to 0.98N·m or less
Applicable standards: CE; EN61010-1, EN61326-1
Over-voltage category: Category II (IEC60364-4-443, IEC60664-1)
Allowable pollution degree: Pollution degree 2
Decoration sheet material/color: Polyester film/Dark gray (DK546)
Case material/color: Reformed PPE/Light gray (DIC650)
Non-detected power failure time: AC power model, Max. 20ms
DC power model, no power failure allowed
■ Accessories and optional parts
* Not UL-certified.
11-4
Chapter 11. SPECIFICATIONS
Name Model No.
Mounting bracket (For C15T) 81446403-001 (Accessory)
Gasket 81409657-001 (Accessory)
Current transformer (800 turns, Hole diameter: 5.8mm) QN206A*
Current transformer (800 turns, Hole diameter: 12mm) QN212A*
Socket (For C15S) 81446391-001
Hard cover 81446442-001
Soft cover 81446443-001
Terminal cover 81446898-001
Smart Loader PackageSLP-C35J50
L-shaped plug adaptor 81441057-001
