Badger Meter ModMAG M2000 User Manual

Troubleshooting Page 38/51
MID_M2000_BA_02_1807
The following error messages can be displayed:
Description Possible Cause Recommended Action
Err: Coil  Meter not connected.
 Connection to meter interrupted.
 Detector electronics or coils
defective.
Check if meter is connected and make
sure that cable connection is not
interrupted.
Otherwise contact Service Department.
Wrn: Pulse
Sync
False synchronization of pulse output
Err: empty pipe Pipe may not be full. Make sure that pipe is always filled at the
measuring point.
Eventually calibrate anew, see calibration
of fluid monitoring
Err: full scale Actual flow rate is exceeding the
programmed.
Reduce flow rate or increase the
programmed full scale.
Err: ADC range Input signal from detector too high. Check the grounding scheme of the
meter installation. See grounding section
in manual.
Err: Tot.
rollover
Number of totalizer digits is exceeded See programming / Info/Help / Totalizer
Rollover
Err: ATOD INT
No measuring signal on analog input.
Contact service.
Some frequently occurring errors are listed in the following:
Other error
Possible Cause
Recommended Action
Meter does not
function
 No auxiliary power.
 Fuse defective.
 Provide auxiliary power.
 Replace fuse.
Fluid is flowing,
however
display shows
zero
 Signal cable is not connected or
connection is interrupted.
 Detector installed opposite to
forward flow direction (see arrow on
type plate).
 Connection cable for coils or
electrodes mixed-up.
 Check signal cable.
 Turn detector by 180°.
 Check connection cable.
Inaccurate
measurement

Wrong parameters.
 Pipe not completely full.

Check parameters (detector,
amplifier and size) as per annexed
data sheet
 Check if measuring pipe completely
full.
When one of the errors occurs, the meter stops measuring until the error disappears; then
the meter resumes the measurement.
