Programming Page 18/51
MID_M2000_BA_02_1807
Pipe Diameter
This figure is used for setting pipe’s diameter (size). Several sizes DN 6
to DN 2000 as well as specific sizes in [mm] can be set.
Note: Pipe diameter is set at the factory. Changes of size have an impact
on meter’s accuracy.
Detector Factor
This parameter is set at the factory. This factor compensates for
accuracy error as a result of the installed detector. If accuracy
adjustment of the meter is required, please refer to the scale factor.
In the event the amplifier is replaced, this parameter must be
reprogrammed with the original detector factor.
Detector Offset
This parameter is set at the
factory. This factor compensates for
accuracy error as a result of the installed detector
adjustment of the meter is required, please refer to the scale factor.
Note: Changes of the detector offset have an impact on meter’s
accuracy at low flow.
5.2.2 Measurement
Velocity Unit
This function lets you select among the velocity units mentioned below.
The units are automatically converted into the selected unit.
• meters/sec
• feet/sec
Flow Units
Flow Units let you select among the Flow Units mentioned below. Flow
units are automatically converted into the selected unit.
