5.1 Quick setup
The M2000 amplifier provides you with a quick setup utility that allows you to quickly
set most of the important parameters like flow units, totalizer units, full scale flow and
low flow cutoff settings.
Flow Units
Flow units let you select among the flow units mentioned below. Flow
units are automatically converted into the selected unit.
Totalizer Unit
This parameter establishes the units of measure for the totalizers:
Full Scale Flow
This parameter sets the maximum flow the system is expected to
measure. This parameter has influence on other system parameters.
These parameters include: Frequency output and current output.
In terms of flow velocity, the meter’s limit are from 0.1 to 12 m/sec.
Moreover the values for Low Flow Cut-off and limits monitoring depend
on Full Scale Flow.
The full scale flow is valid for both flow directions.
Note: If the flow rate exceeds the full scale setting, an error message
indicates that the configured full scale range has been exceeded.
Unit
Unit
LPS
Liter/Second
GPM
Gallons/Min.
LPM
Liter/Minute
GPH
Gallons/Hour
LPH
Liter/Hour
MGD
MegaGallon/Da
M3S
Cubic meters/Sec.
IGS
UKG/Sec.
M3M
Cubic meters/Min.
IGM
UKG/Min.
M3H
Cubic
IGH
UKG/Hour
F3S
Cubic Feet/Sec.
MID
MegaUKG/day
F3M
Cubic Feet/Min.
LbM
Pound/Min.
F3H
Cubic Feet/Hour.
OPM
Ounce/Min
GPS
Gallons/Sec.
BPM
Barrel/Min
Unit
Unit
L Liters UKG Imperial Gallons
HL HectoLiters MIG Mega Imp. Gal.
M³ Cubic Meters Lb Pounds
CFt
Cubic Feet
Oz
Fluid Ounces
USG
U.S. Gallons
Aft
Acre Feet
MG MegaGallons BBL Barrel

Badger Meter ModMAG M2000 Specifications

General

Flow Measurement Technology	Electromagnetic
Enclosure Rating	NEMA 4X (IP66)
Repeatability	±0.1% of rate
Output	4-20 mA, pulse, frequency
Display	LCD with backlight
Power Supply	100 to 240 VAC or 24 VDC
Communication Protocols	HART, Modbus
Process Connection	Flanged, Threaded
Electrode Material	316 Stainless Steel, Hastelloy, Tantalum
Liner Material	PTFE, PFA, Polyurethane
Accuracy	±0.2% of rate
Temperature Range	-40°...160°F (-40°...71°C)
Fluid Temperature	-4°...302°F (-20°...150°C)
Materials	Stainless Steel, Carbon Steel
