Endpoint Status Tool for ORION Cellular Endpoints
ORI-UM-00025-EN-19
5. Select an endpoint in the list to see the endpoint raw read. A window opens, like the examples shown in Figure 51.
OTE:N Information in the first three fields is captured at the time of activation. Information in the next three fields is
current information.
}
}
Information at
time of activation
Current information
}
}
Figure 51: Status detail screen - computer and mobile
The Endpoint Status field displays one of the following:
Endpoint Status Response
Good No response required.
Endpoint Tamper or Encoder Error Incomplete information. This message updates at the next scheduled communication.
Endpoint Tamper Endpoint* requires attention.
Encoder Error Encoder* requires attention.
*For additional endpoint information, see the ORION Endpoint Utility User Manual for handheld or laptop. For additional encoder information, see
the appropriate encoder user manual. All documents are available in the Resource Library at www.badgermeter.com.
The Meter Status field displays one of the following:
OTE:N Meter Status only displays for E-Series Ultrasonic meters. For other meters, the field will have a dash mark (–).
Meter Status Response
Good
No response required.
Sensor Error Meter* requires attention.
*For additional information, see the appropriate E-Series Ultrasonic Meter User Manual, available in the Resource Library at www.badgermeter.com.
6. Tap/click Back to List to return to the previous screen.
7. When nished using the tool, tap the Log Out button or on a mobile device.
Page 28 February 2019
