P/N 133487 13
Banner Engineering Corp. • Minneapolis, U.S.A.
www.bannerengineering.com • Tel: 763.544.3164
SC22-3 Safety Controller
Instruction Manual
Components and Specifications
Interface Modules
SC-IM9 series interface modules are for use only with the SC22-3 Safety Controller; dry contacts for use with higher ac/dc voltage
and current. With 10A output, DIN-mount housing, removable (plug-in) terminal blocks for OSSD outputs (screw terminal block
supplied). Measures approx. 72 mm H, 170 mm D, and 45 mm , 90 mm, or 140 mm W, (2.8" H, 6.7" D, and 1.8", 3.5", or 5.5" W)
depending on model.
NOTE: External device monitoring (EDM) is required to be wired separately to the N.C. contacts to comply with ISO 13849-1
categories and ANSI/OSHA control reliability; see Section 3.6.
Model Description
Supply
Voltage
Inputs
(Safety Controller
Outputs)
Safety
Outputs
Output
Rating
EDM
Contacts
SC-IM9A
For use with 1
SC22-3 safety output
24V dc
(Controller
supplied)
2
(SO1)
3 N.O.
10 amps
1 N.C. pair
per output
SC-IM9B
For use with 2
SC22-3 safety outputs
4
(SO1 and SO2)
Total of 6
(3 N.O. per output)
SC-IM9C
For use with 3
SC22-3 safety outputs
6
(SO1, SO2, and SO3)
Total of 9
(3 N.O. per output)
Model Supply Voltage Inputs Safety Outputs Output Rating EDM Contacts Aux. Outputs
IM-T-9A
24V dc
2 (dual-channel
hookup)
3 N.O.
6 amps 2 N.C.
—
IM-T-11A 2 N.O. 1 N.C.
IM-T-9 series interface modules have 6A output, 22.5 mm DIN-mount housing, removable (plug-in) terminal blocks. Low current
rating of 1V ac/dc @ 5 mA, high current rating of 250V ac/dc @ 6A.
Mechanically Linked Contactors
Provides an additional 10 or 16 amp carrying capability to any safety system. If used, two contactors per safety output pair
(e.g., 2 x SO1), are required. The N.C. contacts are to be used in an external device monitoring (EDM) circuit. (See Figure 3-14.)
Model Supply Voltage Inputs Outputs Output Rating
11-BG00-31-D-024
24V dc 2 (dual-channel hookup)
3 N.O.
and
1 N.C.
10 amps
11-BF16C01-024 16 amps
