SC22-3 Safety Controller
Instruction Manual
Appendix B
The SC22-3 PC-based User Interface (PCI) is the primary tool
for creating and managing configuration files for the Safety
Controller. It’s also used to retrieve, display and store both I/O
and system status and fault information.
The following tutorial explains the steps needed to create a
sample configuration, using the Safety Controller’s PC Interface
(PCI). The configuration is used to define the input devices to be
connected to the Safety Controller and to establish relationships
between those input devices and the Safety Controller outputs.
IMPORTANT: This tutorial is not intended to provide a
comprehensive lesson about every feature the Safety Controller
and PCI offer. Rather, it is designed to provide the basic skills
and processes needed to explore the features on your own.
It also is not intended to explain the operation of the SC22-3
Safety Controller. For complete operational instructions, read
Sections 1–8 of this manual.
Appendix B. Configuration Tutorial — PC Interface (PCI)
B.1 Install the PC Interface Software
• Insert the Banner Safety Controller CD.
• Select Install PC Interface program.
The menu choices identify where the software will be installed
on your computer; in most cases, this location does not need to
be changed and Next should be selected. To install the software
in a different location, select Browse and choose the location to
install the software. When the location is selected, click Next.
• Restart the PC for the PCI program installation to be complete.
B.2 Open the PC Interface Program
To open the PCI,
• Double-click on the icon created on your desktop
-or -
• Select the following series of menu options:
Start → Programs → Banner Engineering → Banner
Safety Controller
• Read and understand the warning on the Start-up Page and
click OK.
