Banner SC22-3 User Manual

100 P/N 133487
Banner Engineering Corp. • Minneapolis, U.S.A.
www.bannerengineering.com • Tel: 763.544.3164
SC22-3 Safety Controller
Instruction Manual
Appendix A
Power
2-Hand Inputs
Mute Enable
Mute Sensor 1
Mute Sensor 2
Backdoor Timer
Safety Output
Max.
Time
Max.
Time
Max.
Time
Max.
Time
Mute cycle prevented
due to open Mute
Enable input
Mute cycle prevented
due to open Mute
Enable input
< 3s< 3s < 3s< 3s
A.11.9 Mute Timing Sequences, continued
Figure A-11. Mute timing diagram with two mute sensors, mute enable, two-hand control and limited mute time.
