Barco ClickShare CS-100 Installation Manual

R5900022-09 ClickShare CS-100 27
2.2 CS-100 specifications
Base Unit
Weight 600g / 1.32lbs
Dimensions (HxWxD) 205mm x 115mm x 45mm (Min.) / 8.1” x 4.5” x 1.8” (Min.)
Power consumption Operation: 6W (typical) / 18W (max)
Standby: 2.6W (ECO standby) / 0.4W (Deep standby)
Operating system Windows 7/8/8.1/10 32 & 64 bit
macOS 10.10/10.11/10.12/10.13 (High Sierra)
Android v5 & v6 & v7 & v8 & 8.1 (ClickShare app)
iOS 8, 9 & 10 & 11 (ClickShare app)
Video outputs 1x HDMI
Frame rate Up to 30 fps
Output resolution 1920x1200
Noise Level Fanless
Number of sources
simultaneous on screen
1
Number of simultaneous
connections
8
Audio Via HDMI, analog via Audio Jack 3.5mm
iPad, iPhone and Android
compatibility
Sharing of documents, browser, camera for both Android and iOS devices
ClickShare app
Extended desktop Available (depending on your operating system). May require ClickShare
Extension Pack.
Authentication protocol WPA2-PSK in stand alone mode
Wireless transmission
protocol
IEEE 802.11 a/g/n
Reach Adjustable with signal strength modulation; max. 30m (100 ft) between
ClickShare Button and ClickShare Base Unit
Frequency band 2.4 GHZ and 5 GHz (DFS channels not supported)
Connections 1x Ethernet LAN
1x (back) + 1x (front) USB
Audio analog line out on mini jack socket (3.5mm)
Temperature range Operating: 0°C to +40°C (+32°F to +104°F)
Max: 35°C (95°F) at 3000m
Storage: -20°C to +60°C (-4°F to +140°F)
Humidity Storage: 0 to 90% relative humidity, non-condensing
Operation: 0 to 85% relative humidity, non-condensing
Anti-theft system Kensington lock
Certifications FCC/CE
Warranty 3 years standard
Google Cast Support Google Cast not supported
CS-100 Specifications

Barco ClickShare CS-100 Specifications

General

Form factor	Desktop
Certification	FCC/CE
Product color	Black, Silver
LED indicators	Yes
Number of users	1 user(s)
Maximum frame rate	30 fps
Supported video modes	1080p
Maximum resolution (HDMI)	1920 x 1200 pixels
Interface	HDMI
Number of HDMI outputs	1
USB 2.0 ports quantity	2
Input voltage	5 V
Output current	0.5 A
Power source type	DC
Power consumption (max)	18 W
Power consumption (standby)	0.4 W
Power consumption (typical)	6 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 85 %
Operating relative humidity (H-H)	0 - 90 %
Antenna type	Internal
Frequency band	2.4 & 5 GHz
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	WPA2-PSK
Maximum operating distance	30 m
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
Mobile operating systems supported	iOS 8.0, iOS 9.0
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	45 mm
Width	115 mm
Height	205 mm
Weight	600 g
