R5900022-09 ClickShare CS-10028
Button
Weight 75 g/0.165 lb
Frequency band 2.4 GHZ and 5 GHz
Wireless transmission
protocol
IEEE 802.11 a/b/g/n
Authentication protocol WPA2-PSK in stand alone mode
WPA2-PSK or IEEE 802.1X in network integration mode
Dimensions (HxWxD) 16.3 mm x 59.3 mm x 162.52 mm / 0.64” x 2.335” x 6.398”
Power consumption Powered over USB-C
5V DC
350mA Typical
500mA Maximum
2.3 About the Base Unit
Base Unit
The Base Unit receives the wireless input from the Buttons and controls the content of the meeting
room display and the sound of the meeting room's audio system.
The Base Unit can be installed in two different ways.
Front and Top layout of the Base Unit
At the front of the Base Unit you can find a power button and a USB Type-A port. Status LED ring is mounted
around the standby button of the Base unit.
Image 2-2
1 USB Type-A port
2 Status LED ring
3 Standby Button
4 Kensington lock
USB port
The USB port is used to update the soft- and firmware of both the Base Unit and the Buttons. For more
information about software update via USB port, see “Firmware update”, page 82.
