6. Important information
Active screen size (H x V) 376 x 302 mm (14.8" x 11.89")
Aspect ratio 5:4
Resolution
1MP (1280 x 1024)
Pixel pitch 0.294mm
Color imaging
Yes
Color support 16.7 million (8-bit)
Viewing angle 178°
Luminance
Default @6500K: 250 cd/m²
Maximum: 300 cd/m² (typical)
Contrast ratio 900:1 (typical)
LCD transition time
Average total 18ms typical
(Rise time Tr + Decay time Tf; Tr = Black to White , Tf = White to Black)
White point Native: 6400K
Calibrated: 5600K, 6500K, 7600K, 9300K
Dot clock
165 MHz (maximum)
Gamma Native, CRT, Xray
Screen protection Dual side anti-reflective Acrylic
Keyboard Mechanical membrane 7 buttons
Video input signals
• DVI-D Single Link (Digital – HDMI video support with HDCP)
•VGA
• Component Video RGBS / YPbPr (4xBNC)
• S-video (4-pin Mini DIN)
• Composite video (1xBNC)
• 3G-SDI (1xBNC)
Video output signals
• DVI-D (output selectable from DVI-1)
• S-video (4-pin Mini DIN)
• Composite video (1xBNC)
• 3G-SDI (1xBNC)
Video formats VGA & DVI : Up to 1920x1200 at 60Hz (reduced blanking)
• Maximum Hor freq: 90kHz
• Maximum pixel clock: 165MHz
• Maximum Ver freq: 75Hz
Standard PAL and NTSC for S-Video, Composite and Component
Component YPbPr/ RGBS: HDTV - up to 1080i & 1080p
SDI Format Supported: 625/25 PAL, 525/29.97 NTSC, 1080i50,
1080i59.94, 1080i60, 720p50, 720p59.94, 720p60, 1080p50,
1080p59.94, 1080p60
SDI Compliance: SMPTE 425M (Level A), SMPTE 424M, SMPTE
292M, SMPTE 259M-C, SMPTE 296M, ITU-R BT.656, ITU-R BT.601
Remote control
RS-232 (D-sub 9-pin)
Power requirements
(nominal)
External power supply: 100-240VAC, 50/60Hz, medical grade
Display power input: +24 VDC ±10% / 1.3 A
44
K5902113 (451920611383) E192HSA 27/11/2017
