R5906852-01 F80 series 107
Operating humidity 20-80% RH (non-condensed)
Storage humidity 20-90% RH (non-condensed)
Dimensions (WxLxH) 480 x 680 x 227 mm / 18.9 x 26.7 x 8.9 in
Weight 25.5 kg / 56.2 lbs
Standard accessories Power cord, wireless remote control
Certifications CE, FCC Class A, cNemkoUS, CCC, EAC, KSA, RCM, UkrSEPRO
Warranty Limited 3 years parts and labor. Extendable up to 5 years
* * SW upgradable. Please contact an authorized Barco representative for
details.<\br> ** When used in long-life mode, available through SW
upgrade
A.5 Dimensions of a F80
Overview
680
227
93
12
589
32
110,5
144 182 60
400
107,5
400
480
4x M6 (Fixation Points up to 15 mm deep
on 400 X 400 Rectangle)
3x M8 (O32 Feet screwed in hole)
Image A-1: Dimensions, in mm
CAUTION: Take care to not exceed the maximum recommended tightening torque on the fixing
screws. Use a torque of 4 Nm for the M8 screws and the M6 screws.
