R5906852-01 F80 series 63
Image 8-3: Installation menu, Orientation
The Orientation menu is displayed.
Image 8-4: Orientation menu
2. Use the ▲ or ▼ key to select the desired mounting position and press OK button to activate.
Use the ▲ or ▼ key to select the desired projection position and press OK button to activate.
8.3 Warping
8.3.1 About warping
Overview
Image warping is the process of digitally manipulating an image to compensate for the distortion of the screen.
Consequently, it can also be used to generate an image with irregular shape.
While an image can be transformed in various ways, pure warping doesn’t affect the colors.
8.3.2 Warping – On/Off
About warping on/off
By toggling between on and off the warping functionality can be enabled or disabled.
How to toggle
1. In the main menu, select Installation → Warp.
Image 8-5: Installation menu, Warp
GUI – Installation
